- Displacement:3.6mL/rev
- Flow Rate Range:1–10L/min
High Pressure in a Compact Micro-Flow Pump
When space is limited but pressure and flow stability are critical, this compact magnetic gear pump delivers a reliable solution. It is engineered to handle very small flow rates while maintaining stable output under high differential pressure. The magnetically coupled design provides a sealed drive system without a conventional dynamic shaft seal, making it suitable for demanding fluid transfer and dosing applications.
Material
Pump casing：SS316L
Gear：peek
Gear shaft：SS316L or nano-ceramic
Internal magnetic drive：PPS overmolded magnet
Sealing ring：FKM/PTFE/FFKM
Optional Motor Configurations
DC Motors (24V): Brushless Motor，Brushed Motor
AC Motors (220V/380V): Three-Phase Motor, Servo Motor
